GPIB Hardware Installation Guide and Specifications | © National Instruments | 29
Environment
Operating ambient temperature 0 °C to 55 °C
(Tested in accordance with IEC 60068-2-1 and
IEC 60068-2-2.)
Operating relative humidity 10% to 90%, noncondensing
(Tested in accordance with IEC 60068-2-56.)
Storage ambient temperature -20 °C to 70 °C
(Tested in accordance with IEC 60068-2-1 and
IEC 60068-2-2.)
Storage relative humidity 5% to 95%, noncondensing
(Tested in accordance with IEC 60068-2-56.)
PXI-8232
Performance
GPIB
3-wire up to 1536 kbytes/s
HS488 up to 7885 kbytes/s
Ethernet interface
10Base-T up to 10 Mbit/s
100Base-TX up to 100 Mbit/s
1000Base-T up to 1000 Mbit/s
Power Requirements
+5 V 917 mA, Typical
1500 mA, Maximum
Physical Characteristics
Dimensions 10.0 cm × 16.0 cm (3.9 in. × 6.3 in.), 3U
Connector
GPIB IEEE 488 24-pin connector
Ethernet RJ-45 with integrated LEDs
