National Instruments MXI-Express Gen-3 x16 User Manual

Waste Electrical and Electronic Equipment (WEEE)
EU Customers At the end of the product life cycle, all NI products must be
disposed of according to local laws and regulations. For more information about
how to recycle NI products in your region, visit ni.com/envir
onment/weee.
电子信息产品污染控制管理办法（中国 RoHS）
中国客户 National Instruments 符合中国电子信息产品中限制使用某些有害物
质指令(RoHS)。关于 National Instruments 中国 RoHS 合规性信息，请登录
ni.com/environment/rohs_china。(For information about China RoHS
compliance, go to ni.com/environment/rohs_china.)
PXIe-8398 (156874x-01L) Specifications
Note These specifications are typical at 25 °C, unless otherwise stated, and are
subject to change without notice.
Physical
Dimensions 10.7 cm × 17.5 cm (4.4 in. × 6.9 in.)
Maximum cable length 3 m
Slot requirements One system slot (PXI Express or CompactPCI
Express)
Compatibility Fully compatible with the PXI Expr
ess
Hardware Specification, Revision 1.0; PICMG
CompactPCI Express EXP.0 R2.0
Specification; and the PCI Express External
Cable Specification, Revision 3.0
Weight 0.36 kg (0.81 lb) typical
Power Requirements
Power Rail Typical Current Maximum Current
+3.3 V 750 mA 1.1 A
+5 V 100 mA 200 mA
+12 V
1
1100 mA 2300 mA
+5 V
AUX
200 mA 500 mA
1
Not including the power consumed by an active cable. NI copper cables (785550-0x) are
passive.
26 | ni.com | MXI-Express Gen-3 x16 User Manual
