NI PXI-4130 Calibration Procedure | © National Instruments | 15
1 200 mA 20 V 20 V 1 4.00 mA ±0.101 mA
2 50.0 mA ±0.115 mA
3 100 mA ±0.130 mA
4 150 mA ±0.145 mA
5 200 mA ±0.160 mA
-20 V 6 4.00 mA ±0.101 mA
7 50.0 mA ±0.115 mA
8 100 mA ±0.130 mA
9 150 mA ±0.145 mA
10 200 mA ±0.160 mA
2A 20 V 1 40.0 mA ±1.05 mA
2 0.5 A ±1.60 mA
3 1.0 A ±2.70 mA
4 1.5 A ±4.68 mA
5 2.0 A ±8.40 mA
-20 V 6 40.0 mA ±1.05 mA
7 0.5 A ±1.60 mA
8 1.0 A ±2.70 mA
9 1.5 A ±4.68 mA
10 2.0 A ±8.40 mA
Table 7. NI 4130 Output Parameters and Test Limits for Current Programming
Accuracy Verification (Continued)
Channel(s)
Current
Limit
Range
Voltage
Level
Range
Vol tag e
Level
Iteration
Output
(A)
Test Limit
