NI PXI-4130 Calibration Procedure | © National Instruments | 11
Verifying Current Programming Accuracy
To verify current programming accuracy, compare a set of requested current test points to
measurements of the actual current at the output by the DMM. Connect an NI APS-4100
auxiliary power supply for this verification procedure. Refer to Figure 3 and Figure 4 for the
necessary connections.
Table 6. NI 4130 Output Parameters and Test Limits for Voltage Measurement
Accuracy Verification
Channel
Voltage Level
Range (V)
Iteration Output (V)
Test Limit (V)
(% of DMM
Measurement +
Offset)
0 6 1 0 ± (0.05% + 4 mV)
2 1.5
3 3
4 4.5
5 6
1 20 1 0 ± (0.03% + 1.5 mV)
2 5
3 10
4 15
5 20
6 -5
7 -10
8 -15
9 -20
