NI PXI-4130 Calibration Procedure | © National Instruments | 17
Table 8. NI 4130 Output Parameters and Test Limits for Current Measurement
Accuracy Verification
Channel(s)
Current
Limit
Range
Voltage
Level
Range
(V)
Voltag e
Level
(V)
Iteration Output
Test Limit ±
(% of reading +
offset)
0 1A 6 0 1 350 mA 0.15% + 4 mA
1
6 2 350 mA
3 700 mA
1 200 μA 20 0 1 50.0 μA 0.03% + 0.02 μA
20 2 50.0 μA
3 0.10 mA
4 0.150 mA
5 0.20 mA
-20 6 50.0 μA
7 0.10 mA
8 0.15 mA
9 0.20 mA
2mA 0 1 0.50 mA 0.03% + 0.2 μA
20 2 0.50 mA
3 1.00 mA
4 1.50 mA
5 2.00 mA
-20 6 0.50 mA
7 1.00 mA
8 1.50 mA
9 2.00 mA
