NI PXI-4130 Calibration Procedure | © National Instruments | 7
Verification of the NI 4130 is complete only after you successfully complete all tests in this
section.
Note If verification fails post-adjustment, confirm that you have met the required
Test Conditions before you return the NI 4130 to NI for repair.
Table 4. Calibration Equipment Configuration for Current Programming and
Measurement Verification/Adjustment
NI 4130 DMM
*
Calibrator
Resistance
Channel Range Function Range
Input
Impedance
†
Resolution
in Digits
0 1A DC
Current
1A N/A 6.5 N/A
1 200 μA DC
Voltage
10 V 10 GΩ 7.5 10 kΩ
2mA DC
Voltage
10 V 10 GΩ 7.5 1kΩ
20 mA DC
Voltage
10 V 10 GΩ 7.5 100 Ω
200 mA DC
Voltage
10 V 10 GΩ 7.5 10 Ω
2A DC
Current
3A N/A 6.5 N/A
* Use the highest resolution available on the DMM.
†
Assumes an NI 4071 DMM. For all other DMMs, use the range and input impedance closest to the
values listed in this table.
