NEC MultiSync EA223WM User Manual

English-16
Specifi cations
Monitor Specifi cations MultiSync EA223WM Notes
LCD Module Diagonal:
Viewable Image Size:
Native Resolution (Pixel Count):
55.87 cm/22.0 inches
55.87 cm/22.0 inches
1680 x 1050
Active matrix; thin fi lm transistor (TFT) liquid crystal
display (LCD); 0.282 mm dot pitch; 250 cd/m
2
white
luminance; 1000:1 contrast ratio (typical), (25000:1
Contrast ratio, Dynamic).
Input Signal
DisplayPort: DisplayPort Connector: Digital RGB DisplayPort Complies with Standard V1.1a,
applicable to HDCP
DVI: DVI-D 24pin: Digital RGB DVI (HDCP)
VGA: 15pin Mini D-sub: Analog RGB
Sync
0.7 Vp-p/75 ohm
Separate sync.TTL level Positive/Negative
Composite sync.TTL level Positive/Negative
Sync on Green
(Video 0.7 Vp-p and Sync Negative 0.3 Vp-p)
Display Colours 16,777,216 Depends on display card used.
Synchronization Range Horizontal:
Vertical:
31.5 kHz to 82.3 kHz (Analog)
31.5 kHz to 82.3 kHz (Digital)
56 Hz to 75 Hz
Automatically
Automatically
Automatically
Viewing Angle Left/Right:
Up/Down:
±85° (CR > 10)
±80° (CR > 10)
Image Formation Time 5 ms (Typ.)
Resolutions Supported 720 x 400*
1
: VGA text Some systems may not support all modes listed.
640 x 480*
1
at 60 Hz to 75 Hz
800 x 600*
1
at 56 Hz to 75 Hz
832 x 624*
1
at 75 Hz
1024 x 768*
1
at 60 Hz to 75 Hz
1152 x 864*
1
at 75 Hz
1152 x 870*
1
at 75 Hz
1280 x 960*
1
at 60 Hz to 75 Hz
1280 x 1024*
1
at 60 Hz to 75 Hz
1440 x 900*
1
at 60 Hz to 75 Hz
1400 x 1050*
1
at 60 Hz to 75 Hz NEC DISPLAY SOLUTIONS cites recommended
1680 x 1050 at 60 Hz........................................... resolution for optimal display performance.
Active Display Area Landscape: Horiz.:
Vert.:
Portrait: Horiz.:
Vert.:
473.8 mm/18.7 inches
296.1 mm/11.7 inches
296.1 mm/11.7 inches
473.8 mm/18.7 inches
USB Hub I/F:
Port:
Load Current:
USB Specifi cation Revision 2.0
Upstream 1
Downstream 4
Maximum 0.5A per port
AUDIO
AUDIO Input: STEREO Mini Jack:
DisplayPort Connector:
Analog Audio
Digital Audio
Stereo L/R 500mV rms 20 Kohm
PCM 2ch 32, 44.1, 48 kHz (16/20/24bit)
Headphone Output: STEREO Mini Jack: Headphone Impedance 32 Ohm
Speakers Practical Audio Output: 1.0 W + 1.0 W
ControlSync IN:
(available up to 5 sub monitors) OUT:
Stereo Micro jack 2.5 φ
Stereo Micro jack 2.5 φ
Power Supply AC 100-240 V ~ 50/60 Hz
Current Rating 0.75 - 0.40 A (with USB and Audio)
Dimensions Landscape:
Portrait:
Height Adjustment:
503.5 mm (W) x 384.0 - 514.0 mm (H) x 218.0 mm (D)
19.8 inches (W) x 15.1 - 20.2 inches (H) x 8.6 inches (D)
329.7 mm (W) x 519.6 - 601.4 mm (H) x 218.0 mm (D)
13.0 inches (W) x 20.5 - 23.7 inches (H) x 8.6 inches (D)
130 mm / 5.1 inches (Landscape orientation)
81.8 mm / 3.2 inches (Portrait orientation)
Weight 5.6 kg (12.3 lbs)/Without stand: 3.3 kg (7.3 lbs)
Environmental Considerations
Operating Temperature:
Humidity:
Altitude:
Storage Temperature:
Humidity:
Altitude:
5°C to 35°C/41°F to 95°F
30% to 80%
0 to 6,562 Feet/0 to 2,000 m
-10°C to 60°C/14°F to 140°F
10% to 85%
0 to 40,000 Feet/0 to 12,192 m
*1 Interpolated Resolutions: When resolutions are shown that are lower than the pixel count of the LCD module, text may appear different. This is normal and
necessary for all current fl at panel technologies when displaying non-native resolutions full screen. In fl at panel technologies, each dot on the screen is actually one
pixel, so to expand resolutions to full screen, an interpolation of the resolution must be done.
NOTE: Technical specifi cations are subject to change without notice.

NEC MultiSync EA223WM Specifications

General

3D	No
HD type	WSXGA+
Panel type	TN
Pixel pitch	0.282 x 0.282 mm
Aspect ratio	16:10
Screen shape	Flat
Backlight type	W-LED
Display diagonal	22 \
Display resolution	1680 x 1050 pixels
Display technology	LED
Maximum refresh rate	60 Hz
Contrast ratio (dynamic)	25000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Digital vertical frequency	56 - 75 Hz
Digital horizontal frequency	31.5 - 82.3 kHz
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1280 x 960, 1366 x 768, 1400 x 1050 (SXGA+), 1440 x 900 (WXGA+), 1680 x 1050 (WSXGA+)
On/off switch	Yes
Power consumption (economy mode)	12 W
USB hub version	2.0
DVI-I ports quantity	-
USB Type-A downstream ports quantity	4
Certification	CE; Energy Star 5.0; FCC Class B; GEEA/Energy Label; ISO 9241-307 (pixel failure class I); MPR III; PCT/Gost; RoHS; TCO 6.0; TÜV Ergonomics; TÜV GS; UL/C-UL, CSA
Product color	White
RMS rated power	2 W
Number of speakers	2
Pivot angle	0 - 90 °
LED indicators	Power
Tilt angle range	-5 - 30 °
Height adjustment	130 mm
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
Power consumption (max)	25 W
Annual energy consumption	18 kWh
Power consumption (standby)	- W
Power consumption (PowerSave)	0.5 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Cables included	AC, DisplayPort, USB
Sustainability certificates	EPEAT Gold, ENERGY STAR

Weight and Dimensions

Depth (with stand)	218 mm
Height (with stand)	384 mm
Weight (with stand)	5600 g
Depth (without stand)	- mm
Width (without stand)	503.5 mm
Weight (without stand)	- g
