REFERENCE ADJUSTMENT
REF. ADJUST menu
Adjustments contained in this menu are criteria. The adjustments are
performed once after installation. The projector has only one data
area for all the registered signals.
Further adjustments are not necessary in normal use. Leave the
settings as they are at the factory.
– REF. ADJUST –
1 / ASTIG
2 / BRIGHT UNIFORM.
3 / WHITE UNIFORM.
4 / RASTER CENTERING
5 / FOCUS BAL.
6 / REF.WHITE BAL
For service personnel only (cannot be selected)
ASTIG menu
Adjustment screen
Adjustment screen
NOTE
Items 4 through 6 cannot be selected as they are for service
personnel only. If you try to select one, the “For service personnel
only” message is displayed at the bottom of the screen.
• Press and hold the CTL button then press to display the “REF.
ADJUST” menu.
The “REF. ADJUST” menu can also be displayed by selecting the
“9/REF. ADJUST” item in the ADJUST menu.
