10
Controls
OSM
™
Controls Menu
Main Menu
OSM controls main menu of icons gives you an overview of the
selection of controls available. When OSM controls are activated,
icons are displayed at the top of the menu.
If an arrow button is displayed, (➔), it indicates further choices
are available. Use the / CONTROL buttons to scroll through
all of the options.
Main Menu
Degauss: Eliminates the buildup of stray magnetic fields which
alter the correct scan of the electron beams and affect the purity
of the screen colors, focus and convergence. When activated,
your screen image will jump and waver a bit as the screen is
demagnetized.
Caution: Please allow a minimum of 20 minutes to elapse
between uses of the Degauss Control.
Size and Position Controls
Left/Right: Moves the image horizontally (left or right).
Up/Down: Moves the image vertically (up or down).
Narrow/Wide: Increases or decreases the horizontal size
of the image.
Tall/Short: Increases or decreases the vertical size of the image.
Geometry Controls
Geometry Controls Menu
The Geometry controls allow you
to adjust the curvature or angle of
the sides of your display.
Sides In/Out (pincushion): In-
creases or decreases the curvature
of the sides either inward or
outward.
Brightness/Contrast Controls
Brightness: Adjusts the overall image and background screen
brightness.
Contrast: Adjusts the image brightness in relation to the
background.
The icons control
the following:
78131791 7/29/98, 9:24 AM12
