5
Quick Start
Connect the MultiSync
®
XV
17
+
™
monitor’s signal cable to the
other end of the cable adapter. Tighten screws on all connectors.
4. Connect one end of the power cable to the MultiSync XV
17
+
monitor and the other end to the power outlet.
5. Turn on your MultiSync monitor and computer.
NOTE: If you have any problems, please refer to the Troubleshoot-
ing section of this manual.
Connection to Other Computers
or Display Cards
If your computer or display card is not compatible with the
MultiSync
XV
17
+
monitor’s PRESET signals or has a different pin
assignment, refer to the steps below to determine if your system is
compatible with the MultiSync
XV
17
+
monitor.
1. Determine the video connector’s pin assignments of your display card.
2. Determine the output signal timing and level of your display card.
3. Check the pin assignment and signal timing charts of the display card and
make sure the monitor accepts these pin assignments and signal timings.
4. Connect the signal cable supplied with your display card to the monitor.
5. Connect one end of the power cable to the MultiSync XV17+ monitor and
the other end to the power outlet.
6. Turn on the monitor and the computer.
7. Adjust the size and position of the image to your preference.
If you have any problems, please refer to the Troubleshooting
section of this manual.
78131791 7/29/98, 9:24 AM7
