NetComm NP505 User Manual

500Mbps Powerline Adapters with AC Pass-through - NP505
4. Connect one end of the other supplied Ethernet cable into the
Ethernet port of any device you want to connect to the Internet (PC,
set-top box, gaming console, PVR, blu-ray player etc).
5. Connect the other end of the cable into the second Powerline adapter.
6. Connect the Powerline adapter to a power point near your device.
NOTE: For best performance plug your Powerline adapters directly into the wall.
Only connect to a powerboard as a last resort as this will reduce performance.
TV
Powerboard
At this point, you can plug another electrical appliance into the Powerline
adapter’s AC pass-through socket if you wish to do so.
Both adapters will take a short time to nd each other. Once they have, all
three lights on both adapters should be on.
NOTE: For best performance connect other electrical devices to the AC Pass-
through socket of the Powerline adapter. If possible, also avoid plugging
other electrical devices into the socket next to the Powerline adapter to
ensure your network performs to its full potential.

NetComm NP505 Specifications

Power

power supply voltage	AC 220-240V
power supply frequency	50-60Hz

Data Transfer and Range

data transfer rate	Up to 500 Mbps over Powerline
range	Up to 200 m over Powerline

Operating Environment

operating temperature	0°C to 40°C
non-operating temperature	-25°C to 70°C
operating humidity	30% to 80% Relative Humidity
non-operating humidity	30% to 95% Relative Humidity

Weight and Dimensions

dimensions	62 mm x 116 mm x 42 mm
weight	200 g
