NetComm NP505 User Manual

NetComm
Wireless
4. Hold the black button on adapter 1 for 2 seconds to complete
the pairing process. When pairing is complete, the LED on both
Adapters will be lit and all adapters will share the same password.
Repeat for any further additions
1
Additional
adapter
(unpaired)
(press for 2 seconds)
Congratulations now you have paired an extra Powerline adapter
QSG-00037 rev2

NetComm NP505 Specifications

Power

power supply voltage	AC 220-240V
power supply frequency	50-60Hz

Data Transfer and Range

data transfer rate	Up to 500 Mbps over Powerline
range	Up to 200 m over Powerline

Operating Environment

operating temperature	0°C to 40°C
non-operating temperature	-25°C to 70°C
operating humidity	30% to 80% Relative Humidity
non-operating humidity	30% to 95% Relative Humidity

Weight and Dimensions

dimensions	62 mm x 116 mm x 42 mm
weight	200 g
