2-1
v1.0, September 2007
Chapter 2 Settings and Maintenance
Basic Settings
You can use the Basic Settings screen to view or change your Internet IP address settings, your
domain name server (DNS) address, and MAC address.
1. Log in to the modem at its default LAN address of http://modemlogin.net with its default
user name of admin, and default password of password, or using whatever user name,
password, and LAN address you have chosen for the modem.
2. On the main menu, select Basic Settings:
The Basic Settings are explained below in the following table.
Figure 2-1
Table 2-1. Basic Settings
Setting Description
Internet IP Address • Get Dynamically from ISP. Your ISP uses DHCP to assign your IP
address. Your ISP automatically assigns these addresses.
• Use Static IP Address. Enter the IP address that your ISP assigned. Also
enter the IP subnet mask and the gateway IP address. The gateway is the
ISP’s modem to which your modem will connect.
