Technical Specifications and Factory Default Settings A-1
v1.0, September 2007
Appendix A
Technical Specifications and Factory Default
Settings
This appendix lists the technical specifications and factory default settings for the modem.
Technical Specifications
Network Protocol and Standards Compatibility
Data and Routing Protocols: TCP/IP, RIP-1, RIP-2, DHCP, RFC 1483 Bridged or Routed
Ethernet
Power Adapter
North America: 120V, 60 Hz, input
United Kingdom, Australia: 240V, 50 Hz, input
Europe: 230V, 50 Hz, input
Japan: 100V, 50/60 Hz, input
All regions (output): 12V DC @ 1.0A
Physical Specifications
Dimensions: 1 in x 6.75 in x 4.5 in (25 x 172 x 114 mm)
Weight: 0.7 lbs. (0.3 kg)
Environmental Specifications
Operating temperature: 32º to 104º F (0° to 40° C)
Operating humidity: 90% maximum relative humidity, noncondensing
Interface Specifications
LAN: 10BASE-T or 100BASE-Tx, RJ-45
WAN: Internal wireless broadband
