NETGEAR Nighthawk AX8 User Manual

•
Try quitting the browser and launching it again.
•
Make sure that Java, JavaScript, or ActiveX is enabled in your browser. If you are
using Internet Explorer, click the Refresh button to be sure that the Java applet is
loaded.
•
Make sure that the IP address of your computer or mobile device is in the same
subnet as the router. If you are using the recommended addressing scheme, the IP
address of your computer or mobile device is in the range of 192.168.1.2 to
192.168.1.254.
•
If the IP address of your computer or mobile device is shown as 169.254.x.x, the
computer or mobile device could not reach the router’s DHCP server and the
Windows or Mac operating system generated and assigned an IP address. Such an
autogenerated IP address is in the range of 169.254.x.x. If your IP address is in this
range, check the connection from the computer or mobile device to the router, and
reboot your computer or mobile device.
•
If your router’s IP address was changed and you do not know the current IP address,
clear the router’s configuration to factory defaults. This sets the router’s IP address
to 192.168.1.1.
Tip: If the router is in access point mode or bridge mode and you do not know the
IP address that is assigned to it, first try to use an IP scanner application to detect
the IP address. (IP scanner applications are available online free of charge.) If you
can detect the IP address, you don’t need to reset the router to factory default
settings.
•
If you are attempting to set up your NETGEAR router as a replacement for an ADSL
gateway in your network, the router cannot perform many gateway services. For
example, the router cannot convert ADSL or cable data into Ethernet networking
information. NETGEAR does not support such a configuration.
You cannot access the Internet
If you can access your router but not the Internet, check to see if the router can obtain
a WAN IP address from your Internet service provider (ISP). Unless your ISP provides a
fixed IP address, your router requests an IP address from the ISP. You can determine
whether the request was successful using the router web interface.
To check the WAN IP address:
1.
Launch a web browser from a computer or mobile device that is connected to the
router network.
2. Select an external site such as https://www.netgear.com/.
User Manual166Troubleshooting
Nighthawk AX8 8-Stream Tri-Band WiFi 6 Router

NETGEAR Nighthawk AX8 Specifications

General

Modulation	1024-QAM
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channel bandwidth	160 MHz
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN data transfer rate (max)	6000 Mbit/s
WLAN data transfer rate (first band)	1200 Mbit/s
WLAN data transfer rate (second band)	4800 Mbit/s
Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Memory card slot(s)	No
Ethernet LAN (RJ-45) ports	5
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
WAN connection type	RJ-45
Processor cores	4
Processor frequency	1800 MHz
Electromagnetic compatibility	FCC 15 B EN 55022 (CISPR 22), B C-Tick N10947
Security algorithms	128-bit AES, WPA, WPA2, WPA2-PSK
Product type	Tabletop router
Product color	Black
LED indicators	LAN, Power, WAN
Output current	3.16 A
Output voltage	19 V
Power source type	AC
AC input frequency	50 - 60 Hz
Package depth	307 mm
Package width	238 mm
Package height	129 mm
Package weight	2380 g
Number of products included	1 pc(s)
Cables included	LAN (RJ-45)
Windows operating systems supported	Windows 10, Windows 2000, Windows 7, Windows 8, Windows Vista, Windows XP
Routing protocols	RIP-1, RIP-2
Data link protocols	TCP/IP, DHCP, PPPoE, PPTP, Bigpond, Dynamic DNS, SMB
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	202 mm
Width	305 mm
Height	161 mm
Weight	1281 g
