New Holland TS-115A User Manual

© 2004 Alamo Group Inc.
11 - 5
Maverick (NH TS-100A,115A, 125A, 135A Asy. Man) 01/05
02981781 Common box Consist of the Following Items:
(Contiuned from previous page)
ITEM PART NO. QTY. DESCRITION
02968167 1 ADAPTER, HYD STRAIGHT 16MB - 8MJ
02981435 1 ADAPTER, HYD 10MB - 10 FJX90 ST
02043600 2 ADAPTER, HYD ELBOW 16MB -16MJ45°
02981369 1 PUMP, LS VARIABLE DISP
02978986 1 PUMP, MED DUTY HYDROSTAT
02981388 1 TANK ASY, HYDRAULIC
02981427 1 HOSE, # 8 - 8FJX - 8FJX90 - 24” LG
02981428 1 HOSE, # 8 - 8FJX - 8FJX90° - 21” LG
02981429 1 HOSE, # 12 - 12FJX - 12FJX - 23” LG
02981430 1 HOSE, # 12 - 12FJX - 12FJX - 31” LG
02981431 1 HOSE, # 4 - 4FJX - 4FJX90 - 35” LG
02981432 1 HOSE, # 4 - 4FJX - 4FJX90 - 20” LG
02981433 1 HOSE, # 20 - 20FJX - 20FJX - 24” LG
02981462 1 HOSE, # 12 - 12FJX - 12FJX90 - 20” LG.
02981986 1 DECAL, HOSE & ELEC CONNECTION
02979473 1 DECAL, AW ISO VG 100
02971123 1 DECAL, WARNING PRESSURIZED TANK
02965262 1 DECAL, WARNING HOSE BURST
02971943 1 DECAL, ALAMO IND YELLOW
02981888 1 ASY, VALVE & FITTINGS
02968896 1 PLASTIC TIE, ORANGE 11LG
02968894 1 PLASTIC TIE, RED 11LG
02971943 1 DECAL, ALAMO IND YELLOW
02982347 1 ADAPTER, HYD 16MB - 10MJ STRAIGHT
02972064 1 ADAPTER, HYD ELBOW 16MB - 8MJIC 90°
18. 02981805 1 ELECTRONIC KIT (includes the following 9 items)
02981374 1 CONTROLLER, 3/AXIS 5 BUTTON
02981375 1 HARNESS, WIRE, CONTROLS
02981376 1 HOUSING, DISPLAY & SWITCH
02981531 1 MODULE, XP2, EXPANSION
02981532 1 MODULE, XT2, EXPANSION
02981533 1 MODULE, XS, EXPANSION
02964028A 1 SWITCH, PUSH PULL
02982252 1 DWG, INST MAVERICK HARNESS
02982340 1 ASY, MDM MODULE & PROGRAM
19. 02981517 2 BOLT, EYE TURNED 1/4”-NC20 X 1”
20. 02976531 10 ADAPTER, HYD ELBOW 6FJX - 6FJX45°
21. 02981953 5 HOSE HANGER, FORMED
22. 02981787 1 BOLT, HEX HEAD 3/4”-NC X 1-1/2” PL GR8
23. 02981988 2 DECAL, JOYSTICK OPERATION
24. 02981992A 1 OPERATORS MANUAL & PARTS MANUAL ASSEMBLY
25. 02918600 6 BOLT, HEX HEAD 3/4”-10NC X 2” PL GR8
26. 00011400 4 BOLT, HEX HEAD 3/8”-NC X 1”
Common Box - Component List
Continued Next Page
