New Holland TS-115A User Manual

© 2005 Alamo Group Inc.
Section 4 - 7
Maverick (NH TS-100A,115A , 125A, 135A Asy. Manl) 01/05
Hydraulic Hose Connections
VS . 125/F
C2
C3
SAE 4
P1
P2
Valve "B" Port to
Diverter valve P1 Port
(G/W Tie)
Valve "A" Port to
Diverter valve P2 Port
(G Tie)
4 Through holes are
mounting holes
Diverter Valve "C1" Port
to Swivel Cyl Base
End Port (G/W Tie)
Diverter Valve "C4" Port
to Swivel Cyl Rod End
Port (G Tie)
Diverter Valve "C2" Port
to Door Cyl Base End
Port (Y/W Tie)
Diverter Valve "C3" Port
to Door Cyl Rod End
Port (Y Tie)
Diverter Valve
FIGURE 5
Pressure
Supply
Port "P"
Return
To Tank
"T"
"B"
"A""A"
"A""A"
"A"
"A"
"B""B"
"B""B"
"B"
Swing
Lift
Telescope
Head Tilt
Head Swivel / Door (To Diverter Valve)
Dipper
G
G/W
OR
R/W
Y/W
B/W
OR/
W
Y
R
B
G/W
G
Six Spool Control Valve
External Wire Connec-
tions for valve are marked
"A" and "B" on Valve &
AA1 thru AA12 on wire
harness connections
AA
11
AA
12
B
A
AA
9
AA
10
B
A
AA
7
AA
8
B
A
AA
5
AA
6
B
A
AA
3
AA
4
B
A
AA
2
AA
1
B
A
