TECHNICAL SPECIFICATIONS Page 55/82
9 TECHNICAL SPECIFICATIONS
9.1 PS8 – LS400
9.1.1 System specifications
PS8 with PS8 TDcontroller
LSub 400 with PS8 TDcontroller
96 dB SPL Nominal - 94 dB SPL Wideband
Nominal Peak SPL @ 1m [b]
50° to 100° Hor. x 55° Vert. Rotatable Horn, 4 positions
Q : 10 Nominal DI : 10 dB Nominal ( f > 1.8 kHz )
120 Hz Active through PS8TD
The PS8 TDcontroller is precisely matched to the PS8 & LS400 cabinets and includes sophisticated protection
systems. Using PS8 & LS400 without a properly connected PS8TD will result in poor sound quality and can
damage the components. PS8 & LS400 can also be used with NXAMP4x1 and NXAMP4x4 Powered
TDControllers.
After dismounting the front grille from its fixings, the HF Horn can be rotated in 4 positions for dispersion
configuration.
The PS8 can be used without optional LS400 Subbass. Active two-way operation with the LS400 is included in
the PS8TD. One LS400 matches 2 x PS8, additional LS400 may be used for enhanced LF capability.
PS8 are wired 2- & 2+ on Speakon connectors, LS400 on 1- & 1+. Loop through Speakons are present on both.
Single identical cables can thus be used to loop through combinations of up to 2 x PS8 & 1 x LS400 in no
particular order.
1 x 8" (20cm) Shielded Neodymium 8 driver
1 x 1" Shielded Neodymium throat driver + Low Distorsion,
Constant Directivity Asymetrical Dispersion Horn.
1 x 12" ( 30cm ) long excursion 6 Ohm driver
-
406 x 250 x 219 mm (16"x 9 7/8"x 8 5/8")
338 x 500 x 406 mm (13 1/4’’x 19 5/8’’x 16")
Baltic Birch Ply finished with structured black coating
Baltic Birch Ply & structured black coating
Molded Dark Grey Metal Grill
Flying Points & Fixed Installation
Threaded inserts are fitted as standard to all cabinet surfaces
for connection of mounting accessories
Built in Stand Fitting, 35mm (1"3/8)
Internal Stand Fitting on Top (35mm, 1"3/8)
allows pole mounting ofr 1 PS8.
As part of a policy of continual improvement, NEXO reserves the right to change specifications without notice.
[a] Response curves & data : Anechoïc Far Field for the PS8 + PS8TD. Half-Space Anechoïc radiation for the LS400 + PS8TD.
[b] Sensitivity & Peak SPL data : these will depend on spectral distribution and crest factor of program material. Measured with band
limited Pink Noise. Nominal refers to Voice Decade (300 Hz - 3 kHz), Wideband to the specified ±3dB range. Data are for speaker +
processor + recommended amplifier combinations. Peak SPL is at clipping of recommended amplifier.
[c] Directivity curves & data : obtained by computer treatment on off axis response curves.
