Nice D-Pro Automatic R01 Series User Manual

English – 9
EN
Motherboard D-PRO Automatic - 2.2kW
Connection for wire
antenna or external
antenna Connection with
coax cable.
OXI receiver slot
Voltage free contact for
red trafc light
Voltage free contact
for top end position
indication
Voltage free contact for
bottom end position
indication
Connection for 200V
DC electromechanical
brake
Starter condenser
board connector
Motor terminals
PE terminals
Select lower
sensitive
edge
Controller
board
Sensitive edge
terminal clamps
Mains terminals
Transit photocell
terminal clamps
Key switch connector
Mechanical limit
switch terminal
clamps
Limit switch 1/2
OPEN terminal
clamps
N.O. VOLTAGE FREE
CONTACT CLOSE
Keypad
N.O. VOLTAGE FREE
CONTACT JOG
Keypad
N.O. VOLTAGE FREE
CONTACT OPEN
Keypad
N.C. VOLTAGE FREE
CONTACT OPEN
Keypad
TYKO Mini-Fit
digital limit switch
connector
Digital limit switch
terminal clamps
Terminal clamps
