Nikon D80 User Manual

88 Menu Guide / Custom Settings
5: No Memory Card? (All Modes)
If Release locked (the default setting) is selected, the shutter-release
is disabled when no memory card is inserted. Choose Enable release
to enable the shutter-release button when no memory card is inserted.
Photographs will be displayed in the monitor but will not be saved.
6: Image Review (All Modes)
If On (the default setting) is selected, photographs will automatically
be displayed in the monitor for about for seconds after shooting. If Off
is selected, photographs can be displayed in the monitor by pressing
the button.
7: ISO Auto (P, S, A, and M Modes Only)
If Off (the default setting) is selected, ISO sensitivity will remain fi xed at
the value selected with the ISO button ( 43) or using the ISO sensitiv-
ity option in the shooting menu ( 83).
If On is selected, ISO sensitivity will automatically be adjusted if optimal exposure can not be
achieved at the selected value (fl ash level is adjusted appropriately). The maximum value for
auto ISO sensitivity can be selected using the Max. sensitivity option. In modes P and A,
sensitivity will only be adjusted if underexposure would result at the shutter speed selected
for Min. shutter speed.
When On is selected, the control panel and viewfi nder show ISO-AUTO.
When sensitivity is altered from the value selected by the user, these
indicators blink and the altered value is shown in the viewfi nder (the
indicators do not blink if a fl ash is used.
ISO Auto
Auto ISO control is not available when a value over ISO 1600 is selected for ISO sensitivity. ISO sen-
sitivity can not be set to values over 1600 when On is selected for ISO auto. Foreground subjects
may be underexposed in photos taken with the fl ash at slow shutter speeds, in daylight, or against a
bright background. Choose a fl ash mode other than slow sync or select mode A or M and choose a
larger aperture.
Noise is more likely at higher sensitivities. Use the High ISO NR option in the shooting menu to
reduce noise (
83).

Nikon D80 Specifications

General

Field of view	170 %
Display diagonal	2.5 \
Vari-angle LCD display	No
Display resolution (numeric)	230000 pixels
Megapixel	10.2 MP
Camera type	SLR Camera Body
Sensor type	CCD
Sensor format	DX
Total megapixels	10.75 MP
Image sensor size	- \
Image formats supported	EXIF, NEF, RAW
Maximum image resolution	3872 x 2592 pixels
Image sensor size (W x H)	23.6 x 15.8 mm
Still image resolution(s)	L (3872 x 2592) M (2896 x 1944) S (1936 x 1296)
Digital zoom	- x
Mounting type	Bayonet
Focal length range	27 - 202.5 mm
Lens mount interface	Nikon F
Built-in flash	Yes
Power source type	Battery
PictBridge	-
USB version	2.0
USB connector	Mini-USB B
Product color	Black
Battery type	EN-EL3e
Number of batteries supported	1
Flash modes	Red-eye reduction, Second curtain synchro, Slow synchronization
Flash sync-speed	0.005 s
Flash range (wide)	- m
Flash exposure correction	-3EV - +1EV (1/3 EV step)
Compatible memory cards	SD, SDHC
Eye relief	19.5 mm
Scene modes	Close-up (macro), Night landscape, Night portrait, Portrait, Sports, Landscape (scenery)
Image editing	Resizing, Rotating, Trimming
Photo effects	Black&White, Sepia, Vivid
White balance	Auto, Fine, Flash, Fluorescent, Incandescent, Shade, Sunny
Shooting modes	Aperture priority, Auto, Manual, Program, Shutter priority
Camera playback	Single image, Thumbnails
Self-timer delay	2, 3, 5, 10, 12, 20 s
Languages support	CHI (SIMPL), CHI (TR), DEU, DUT, ENG, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE
Diopter adjustment (D-D)	-2 - 1
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) points	11
Auto focusing (AF) modes	Multi Point Auto Focus, Servo Auto Focus, Single Auto Focus
Auto Focus (AF) points selection	Auto
Light metering	Centre-weighted, Matrix, Spot
ISO sensitivity	100, 1600
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	1600
ISO sensitivity (min)	100
Light exposure correction	± 2EV (1/3EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	30 s
Cables included	AV, USB
HD type	Not supported
Maximum video resolution	- pixels
Analog signal format system	NTSC, PAL
Magnification	0.95 x
Viewfinder type	Optical

Weight and Dimensions

Depth	77 mm
Width	132 mm
Height	103 mm
Weight	585 g
