Nikon D80 User Manual

11Introduction: First Steps
Attaching a Lens
Care should be taken to prevent dust from entering the camera when the lens is removed.
1
Turn the camera off .
2
Remove the rear cap from the lens.
Remove the camera body cap.
3
Keeping the mounting index on the lens aligned with the
mounting index on the camera body, position the lens in the
camera’s bayonet mount and rotate the lens in the direction
shown until it clicks into place.
If the lens is equipped with an A-M or M/A-M switch, select A
(autofocus) or M/A (autofocus with manual priority).
Detaching Lenses
Be sure the camera is off when removing or exchanging lenses. To remove the lens, press and hold
the lens-release button while turning the lens clockwise. After removing the lens, replace the camera
body cap and rear lens cover.
Aperture Ring
If the lens is equipped with an aperture ring ( 45, 117), lock aperture at the minimum setting (highest
f/-number). See the lens manual for details.
First Steps

Nikon D80 Specifications

General

Field of view	170 %
Display diagonal	2.5 \
Vari-angle LCD display	No
Display resolution (numeric)	230000 pixels
Megapixel	10.2 MP
Camera type	SLR Camera Body
Sensor type	CCD
Sensor format	DX
Total megapixels	10.75 MP
Image sensor size	- \
Image formats supported	EXIF, NEF, RAW
Maximum image resolution	3872 x 2592 pixels
Image sensor size (W x H)	23.6 x 15.8 mm
Still image resolution(s)	L (3872 x 2592) M (2896 x 1944) S (1936 x 1296)
Digital zoom	- x
Mounting type	Bayonet
Focal length range	27 - 202.5 mm
Lens mount interface	Nikon F
Built-in flash	Yes
Power source type	Battery
PictBridge	-
USB version	2.0
USB connector	Mini-USB B
Product color	Black
Battery type	EN-EL3e
Number of batteries supported	1
Flash modes	Red-eye reduction, Second curtain synchro, Slow synchronization
Flash sync-speed	0.005 s
Flash range (wide)	- m
Flash exposure correction	-3EV - +1EV (1/3 EV step)
Compatible memory cards	SD, SDHC
Eye relief	19.5 mm
Scene modes	Close-up (macro), Night landscape, Night portrait, Portrait, Sports, Landscape (scenery)
Image editing	Resizing, Rotating, Trimming
Photo effects	Black&White, Sepia, Vivid
White balance	Auto, Fine, Flash, Fluorescent, Incandescent, Shade, Sunny
Shooting modes	Aperture priority, Auto, Manual, Program, Shutter priority
Camera playback	Single image, Thumbnails
Self-timer delay	2, 3, 5, 10, 12, 20 s
Languages support	CHI (SIMPL), CHI (TR), DEU, DUT, ENG, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE
Diopter adjustment (D-D)	-2 - 1
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) points	11
Auto focusing (AF) modes	Multi Point Auto Focus, Servo Auto Focus, Single Auto Focus
Auto Focus (AF) points selection	Auto
Light metering	Centre-weighted, Matrix, Spot
ISO sensitivity	100, 1600
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	1600
ISO sensitivity (min)	100
Light exposure correction	± 2EV (1/3EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	30 s
Cables included	AV, USB
HD type	Not supported
Maximum video resolution	- pixels
Analog signal format system	NTSC, PAL
Magnification	0.95 x
Viewfinder type	Optical

Weight and Dimensions

Depth	77 mm
Width	132 mm
Height	103 mm
Weight	585 g
