Nikon DS-L1 User Manual

IX Technical Specifications
2 DS Camera Head DS-5M
- 159 -
Recorded image
Recorded image file
format
JPEG compliant, BMP 24-bit
Image file size
2560
×
1920, 1280
×
960, 640
×
480
JPEG compression
mode
Fine, Normal, Basic, Draft
Interface
CF card Type I, Type II
USB1.1 host interface USB mouse, USB keyboard, USB printer (CP900D) connectable, Nikon 80i/90i
microscope
USB2.0 device
interface
Mass storage class supported, PictBridge supporting printer connectable
Direct print CP900D made by Mitsubishi Electric or a PictBridge supporting printer connectable
Network IEEE802.3 compliant, 10BASE-T/100BASE-TX, DHCP supported
HTTP server, Telnet server, FTP server, FTP client
General
External dimensions
203(W)
×
202(H)
×
73(D) mm (not including protrusions)
Weight 1.3 kg
Rated input voltage
12 VDC
±
5%
Power consumption Approx. 138 VA
Structure of fixed part
VESA (75mm) standard 75-mm pitch, M4
×
7 fixing screw holes, 4 locations
UL1678-suited stand and mount
2
DS Camera Head DS-5M
Image pickup device 2/3-inch square, 5,240,000-pixel IT-CCD
Frame rate 3.75 fps (5Mi), 7.5 fps (1.3Mp), 6.8 fps (1.3Mi), 15 fps (1.3Mp C.Scan)
Quantization 12 bits
Sensitivity Equivalent to ISO64 to 3200 in terms of film sensitivity
(Tone 3, camera sensitivity: x1 to x46)
Lens mount C mount
Usable lens: Protruding no more than 10 mm from the mount surface into the camera
Effective luminous flux: Telecentric system F2.8
Image circle: 2/3-inch, 11 mm in diameter
External dimensions
91(W)
×
76(D)
×
41(H) mm
Weight 230 g
Fixing tripod mount Tripod screw for camera
