41
(1) Model Name: ECLIPSE E100 (Microscope basic unit)
(2) Optical System: CFI optical system (infinity - corrected CF optical system)
2nd objective lens focal length : f = 200 mm
Built-in diascopic illumination system (Simplified Kohler’s illumination system)
(3) Focusing Mechanism: Fine focus knob graduation: 2 µm/graduation
Fine focus knob travel: 0.2 mm up or down / revolution
Coarse focus knob travel: about 37.7 mm up or down / revolution
Stage vertical movable range: 2 mm upward and 20 mm downward from the
focal plane.
(4) Stage: Stroke: X axis: 78 mm
Y axis: 40 mm
(5) Revolving Nosepiece: 4-hole fixed type
(6) Electrical Specifications
・Lamp Rating: Halogen lamp 6V-20W (PHILIPS 7388 or OSRAM HLX 64250)
・Output Rating: 6V 3.3A max.
・Input Rating: Model for 100, 110, and 120 V AC Areas
・Input voltage: Select from 100 V, 110 V or 120 V AC by relocating the
fuse holder in the AC inlet.
・Frequency: 50
-
60 Hz
・Voltage fluctuation: ±10%
・Rated current: 0.5 A
・Fuse rating: 250 V, 1A, time-lag low-breaking type, 5 x 20 miniature
fuse x 2
・Power Cord: Use only the following power supply cord. Using the
wrong power cord could result in danger or fire. The
protection Class I equipment should be connected to
PE (protective earth) terminal.
・UL listed detachable power cord set. 3-conductor
grounding type SVT, No.18 AWG, 3 m long
maximum, rated at 125 V AC minimum.
Specifications
