Dimensional drawing Comfort 350 Top
All listed measurements are in mm.
Right version:
Left version:
Connections:
1. Outdoor air
2. Supply air
3. Extract air
4. Discharge air
5. Condensate drain
NB! Spouts for inlet ring
13
42
5
550
Ø 160
119180
119180
109 109
148 148
105
559
790
3
4
1
2
5
550
Ø 160
119180
119180
109 109
148 148
105
559
790
