Get started
Keys and parts (front)
1 Proximity sensor
2 Earpiece
3 Touch screen
4 Call key
5 Menu key
6 Light sensor
7 Secondary camera
8 End/Power key
Do not cover the area above the touch
screen, for example, with protective film
or tape.
Keys and parts (top)
1 Nokia AV connector (3.5 mm) for
compatible headsets and headphones
2 USB connector
Keys and parts (sides)
1 Memory card slot cover
2 Volume up/Zoom in key
3 Volume down/Zoom out key
4 Lock switch
5 Capture key
Keys and parts (bottom)
1 Charger connector
2 Microphone
3 Wrist strap eyelet
Keys and parts (back)
12 Get started
© 2010 Nokia. All rights reserved.
