Nokia Flexi Zone Micro High Power 2x20 W BTS User Manual

Figure2
FlexiZoneMicroBTSclearances
Right
Front
Rear
Bottom
Top
Left
Procedure
1 Disassemble the mounting bracket.
Themountingbracketconsistsoftwoelements:theinterfacebracketandstatic
bracket.Loosenthetwothumbscrews(M6),slideuptheinterfacebracketandput
asidethestaticbracket.Notethatthumbscrews(M6)areintegralpartsofthe
interfacebracket.
InstallingandCablingFlexiZoneMicroHighPower
2x20WBTS
InstallingFlexiZoneMicroBTS
Issue:02 DN09229011 11
 

Nokia Flexi Zone Micro High Power 2x20 W BTS Specifications

General

Brand	Nokia
Model	Flexi Zone Micro High Power 2x20 W BTS
Category	Network Hardware
Language	English
