5 Tighten the straining straps around the pole.
6 Install the BTS to the static mounting bracket.
w
NOTICE:Ifyoulifttheunitwitharope,useanM6sizeeyeboltwithaM6x1.0thread.
TheeyeboltshouldbefixedtothetopoftheBTS,inplaceoftherubberplug.The
eyeboltshouldberemovedandreplacedwiththerubberplugafterinstallingtheBTS.
Theeyeboltisnotpartofthedeliveryandmustbeorderedseparately.
Figure17
Rubberpluglocation
Rubberplug
a) PositiontheBTSwiththeinterfacebracketaligneddirectlyabovethestatic
mountingbracket.
b) SlidedowntheBTSuntilitisfullylocatedandseatedontothestaticbracket.
c) Handstartthethumbscrews(M6)tosecuretheBTStothestaticbracket.
d) TorqueallM6screwsto5.1Nm(3.8ft-lb).
InstallingFlexiZoneMicroBTS InstallingandCablingFlexiZoneMicroHighPower
2x20WBTS
22 DN09229011 Issue:02
 
