Figure21
FlexiZoneMicroBTSclearances
Right
Front
Rear
Bottom
Top
Left
Procedure
1 Disassemble the mounting bracket.
Themountingbracketconsistsoftwoelements:theinterfacebracketandstatic
bracket.Loosenthetwothumbscrews(M6),slideuptheinterfacebracketandput
asidethestaticbracket.Notethatthumbscrews(M6)areintegralpartsofthe
interfacebracket.
InstallingFlexiZoneMicroBTS InstallingandCablingFlexiZoneMicroHighPower
2x20WBTS
26 DN09229011 Issue:02
 
