ID50 Series Panel - Operating Manual
Operator Actions at Panel
27 997-264-000-8, Issue 8
January 2007
Press ALL keys to exit . . .
0 . . 9 0 MENU 1 2 3 4 5 6 7 8 9 A B C D E
4.9.7 Keyboard - User Option
This option allows the panel keyboard to be functionally
tested.
1 Using the numeric keypad, press ’
1
’ to display the
TEST menu.
2 Press the ‘
2
/
8
’ pushbuttons to display the next
screen options. To test the keyboard, press the ‘
7
’
button on the numeric keypad.
3 The following screen is displayed. Press each panel
pushbutton in turn. When a pushbutton is pressed, the
corresponding display entry is replaced by an equivalent
number of asterisk (*) characters. The five pushbuttons
are represented by A to E, where A is the top button.
Once all pushbuttons have been pressed the display
will return to the test menu. The keyboard test will
automatically abort after one minute if no key is pressed.
[U0] 1 : Test 2 : Disable/Enable 3 : Clock
4 : View Mode 5 : Commission 6:Print
The standard function of the
control keys is suppressed
while this test is active.
Normal function resumes
upon test completion.
7
[U0 Test] 6:Buzzer 7:Keyboard
↕ : More
1
4.9.6 Buzzer - User Option
The Buzzer User Option, selected from the Test Menu,
tests the internal buzzer. Proceed as follows:
1 Using the numeric keypad, press ’
1
’ to display the
TEST menu.
2 Press the ‘
2
/
8
’ pushbuttons to display the next
screen options. To test the buzzer, press the ‘
6
’
button on the numeric keypad.
3 The buzzer sounds with a 2:1 mark:space ratio and
the LCD flashes the message below. Press the ‘
4
’
button to cancel the test and return to the Test Menu.
[U0] 1 : Test 2 : Disable/Enable 3 : Clock
4 : View Mode 5 : Commission
[U0 Test] 6:Buzzer 7:Keyboard
↕ : More
1
TESTING BUZZER ! ! !
6
