Olympus dm-770 User Manual

1
19
EN
Turning the power OFF
Existing data, mode settings and the clock setting are saved when the power is turned off.
1
Slide the POWER / HOLD switch in
the direction of the arrow for at
least half a second.
• The playback stop position at power
OFF is stored in memory.
TIP
• Turning the power OFF whenever the
voice recorder is not in use minimizes
battery consumption.
Power Save mode
When the voice recorder has been
stopped for at least 10 minutes (default
setting) after power ON, the display
disappears and the voice recorder
automatically enters the Power Save
mode.
• Pressing any button releases the
Power Save mode.
Turning the power OFF

Olympus dm-770 Specifications

General

Product color	Silver
Speaker power	0.15 W
Menu languages	DEU, ENG, ESP, FRE, ITA, RUS, SWE
Voice activation	Yes
Headphone outputs	1
Number of folders messages	5
Number of messages per folder	200
MP3 bit rates	8 - 320 Kbit/s
Playback time	35 h
Frequency range	20 - 23000 Hz
Recording modes	-
Maximum recording time	2020 h
Audio formats supported	MP3, PCM, WAV
Display type	LCD
Backlight color	Blue
Display diagonal	1.36 \
Display size (HxV)	26.1 x 22.6 mm
Media types supported	Internal memory & flash card
Compatible memory cards	MicroSD (TransFlash), MicroSDHC
Built-in memory capacity	8 GB
Interface	3.5mm
USB connector type	USB Type-A
Loudspeaker diameter	18 mm
Compatible battery sizes	AAA
Bundled software	Olympus Sonority
Mac operating systems supported	Mac OS X 10.0 Cheetah, Mac OS X 10.1 Puma, Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
Cables included	USB
Harmonized System (HS) code	85198900

Weight and Dimensions

Depth	14.4 mm
Width	39.6 mm
Height	105.9 mm
Weight	72 g
