Olympus dm-770 User Manual

1
7
EN
Setup
Setup
After unpacking the voice recorder, follow the steps below to have it ready for use.
Getting
started
1
3
Inserting the battery
Getting
started
2
3
Turning the power ON
Getting
started
3
3
Selecting the battery setting
Select the battery setting to match the inserted battery. Select the setting
for a nickel-metal hydride rechargeable battery or the setting for an alkaline
battery.
Getting
started
4
3
Setting the time/date
Set the voice recorder’s clock for use with file management.
Getting
started
5
Setting the voice guidance
Remove the screen
protector on the
display.
Getting started
Attaching the strap:

Olympus dm-770 Specifications

General

Product color	Silver
Speaker power	0.15 W
Menu languages	DEU, ENG, ESP, FRE, ITA, RUS, SWE
Voice activation	Yes
Headphone outputs	1
Number of folders messages	5
Number of messages per folder	200
MP3 bit rates	8 - 320 Kbit/s
Playback time	35 h
Frequency range	20 - 23000 Hz
Recording modes	-
Maximum recording time	2020 h
Audio formats supported	MP3, PCM, WAV
Display type	LCD
Backlight color	Blue
Display diagonal	1.36 \
Display size (HxV)	26.1 x 22.6 mm
Media types supported	Internal memory & flash card
Compatible memory cards	MicroSD (TransFlash), MicroSDHC
Built-in memory capacity	8 GB
Interface	3.5mm
USB connector type	USB Type-A
Loudspeaker diameter	18 mm
Compatible battery sizes	AAA
Bundled software	Olympus Sonority
Mac operating systems supported	Mac OS X 10.0 Cheetah, Mac OS X 10.1 Puma, Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
Cables included	USB
Harmonized System (HS) code	85198900

Weight and Dimensions

Depth	14.4 mm
Width	39.6 mm
Height	105.9 mm
Weight	72 g
