Operation
4
4.2 Control From the Front Panel
39
Selecting the User Setup
Select the user setup registered in “Save” in USER
PRESET menu.
1
Press the “LOAD USER” button on the front panel
(see Figure 4.2).
Figure 4.2
The monitor and LCD panel display the current
setup for a few seconds. On the monitor, the user
number currently selected is displayed in green (see
Figure 4.3).
Figure 4.3
2
While the monitor or LCD panel is as shown in
Figure 4.3, press the “LOAD USER” button, “b” or
“B” until the desired user number is displayed.
Each press of the “LOAD USER” button or “B”
changes the user number by one as “1” “2” “3”
“1” ….
Each press of “b” changes the user number by one
as “1” “3” “2” “1” ….
NOTE
The user setup can also be selected in the menu. The
setup made using the above procedure is also applied to
the setup using the menu. For details on menus, see
“Setting “Select”” on page 53.
Ta bl e 4. 1
User
numbers
Settings
1 Suitable for printing a normal/ultrasonic
endoscope image
2 Suitable for printing a normal/surgical
endoscope image
3 Suitable for printing a normal/ultrasonic
endoscope image
LOAD USER button
Monitor
User NumberUser Name
LCD panel
To Next Page
