Connection Configuration
This section describes the connection configuration of the PMAC and NJ/NX-series CPU Unit that you
will set in this guide.
Originator Target Connection I/O Type Size RPI
Number of con-
nections
NJ/NX-series CPU
Unit
PMAC Exclusive Owner 504 bytes each for input
and output
50 ms 16
The correspondence of variables between each node is listed below.
Variable name on the NJ/NX-series CPU Unit side Variable name on the NJ/NX side
eip_from_ppmac_XX
(XX: Connection number)
Eip[XX].Output.Udata[YY]
(XX: Connection number, YY: Number of array elements)
eip_to_ppmac_XX Eip[XX].Input.Udata[YY]
2 Target Device and System Configuration
2-4
CK3E/CK3M/CK5M Series EtherNet/IP Connection Guide (O903)
