E52
45
Model Number Legend
The type of protective tubing length, and lead length can be specified as shown below.
Example:
Element: K, protective tubing length: 12 cm, exposed leads, Y-type crimp terminals for M3.0, protective tubing diameter: 1 mm, flexible and heat
resistive, lead length: 2 m
E52-CA12AY D=1 S2 2M
Dimensions
*1. Lead wires (compensating conductor) (excluding Y-type crimp terminals)
Heat-resistance model (0 to 200°C): PFA glass-wool sheath with stainless outer shield
Flexible, heat-resistance model (0 to 200°C): PFA glass-wool sheath with stainless outer shield
*2. Temperature range of sleeve: 0 to 260°C
*3. The sheath can be easily bent. Performance will not be adversely affected even if the sheath is bent somewhat.
Do not bend the sheath beyond the following value.
Minimum bending radius: 2 mm
Bendable section: 8 mm or farther from the end
Special models for Packaging Machines
E52-CA AY D=1 S M
Code Element type
CA K
Diameter (D) Length (L)
1.0 6
1.0 12
1.0
3 to 100
(in centimeters, variable)
Code Terminal type
A Exposed lead wires
Code Terminal processing
Y
Y-type crimp terminals for M3.0
Code
Lead wire length M (m)
Specify the M length in meters.
Range: 0.5, 1, 2, or 0.5 to 12 (in meters, variable)
Protective tubing length L (cm)
Specify the length in centimeters within the
following range: Unit (cm)
Protective tubing diameter (D)
D=1 1 mm
Protective tubing structure
Sheathed
Code
Application
S Temperature sensors for packaging machines
Code Compensating conductor
2
Flexible and heat resistant (30 cores)
1
Heat resistant (7 cores)
1 ±0.05 dia.
Shrinkable tube (blue)
Lead wire *1
Sheath (ASTM316L) *3
Sleeve (PPS resin) *2
Product label
90±10
(80)30±5
L±3% M±4%
S1: 5.5 dia.
S2: 6.4 dia.
S1: 2.8 dia.
S2: 3.6 dia.
Red: +
White: −
+
+
−
−
30
Y-type crimp terminals for M3.0
Mark tube (white)
