SECTION 6 Communications Data for Modbus

6-6

Address Parameter name Setting (monitor) value Level

0800 Input digital filter H'00000000 to H'0000270F (0.0 to 999.9) Advanced

function

setting

0900 Set point 0 SP lower limit to SP upper limit Adjust-

ment

0904 Alarm value 1 H'FFFFF831 to H'0000270F (−1999 to 9999) Operating

0906 Upper-limit alarm 1 H'FFFFF831 to H'0000270F (−1999 to 9999)

0908 Lower-limit alarm 1 H'FFFFF831 to H'0000270F (−1999 to 9999)

090A Alarm value 2 H'FFFFF831 to H'0000270F (−1999 to 9999)

090C Upper-limit alarm 2 H'FFFFF831 to H'0000270F (−1999 to 9999)

090E Lower-limit alarm 2 H'FFFFF831 to H'0000270F (−1999 to 9999)

0910 Alarm value 3

(See note 2.)

H'FFFFF831 to H'0000270F (−1999 to 9999)

0912 Upper-limit alarm value 3

(See note 2.)

H'FFFFF831 to H'0000270F (−1999 to 9999)

0914 Lower-limit alarm value 3

(See note 2.)

H'FFFFF831 to H'0000270F (−1999 to 9999)

091C Set point 1 SP lower limit to SP upper limit Adjust-

ment

0938 Set point 2 SP lower limit to SP upper limit

0954 Set point 3 SP lower limit to SP upper limit

0A00 Proportional band H'00000001 to H'0000270F (0.1 to 999.9)

0A02 Integral time H'00000000 to H'00000F9F (0 to 3999)

0A04 Derivative time H'00000000 to H'00000F9F (0 to 3999) (Range when RT is

“OFF.”)

H'00000000 to H'0000270F (0.0 to 999.9) (Range when RT is

“ON.”)

0A0A MV upper limit Standard: MV lower limit + 0.1 to H’0000041A (MV lower

limit + 0.1 to 105.0)

0A0C MV lower limit Standard: H’FFFFFFCE to MV upper limit − 0.1 (−5.0 to MV

upper limit − 0.1)

Heating and cooling: H'FFFFFBE6 to H'00000000 (−105.0

to 0.0)
