E8F2 E8F2
14
One-point teaching
Pressure
value
Tw o-point teaching
Pressure
value
ON
OFF
Output
ON
OFF
Output
Note: Auto-teaching will be possible if a is selected in the pressure setti ng method selection in basic setting mode.
Auto-teaching
Auto-teaching all ows input measured values to be input as ON- and OFF-point set val ues instead of key i nput. One- or two-point auto-
teaching can be selected.
1. P ress the SET key to set the E 8F 2 to pressure setting mode and to display OUT1 and t.h1.
2. P ress the Up or Down key to select the one-point teaching or two-point teaching method of OUT1 and OUT2.
Setti ng i tem
Auto-teaching
OUT1 two-point teaching OUT1 one-point teaching OUT2 two-point teaching OUT2 one-point teaching
t.h1: Teach hysteresis mode at first point
t.w: Teach w indow mode
OUT1 OUT2kPa Torr Psi
OUT1 OUT2
kPa Torr Psi OUT1 OUT2kPa Torr Psi
Measurement
mode
OUT1 OUT2 kPa To rr Psi
OUT1 OUT2 kPa To rr Psi
Two-point Teaching (Hysteresis-mode Teaching)
Present measurement
value is displayed.
Present measurement
value is displayed.
OUT1 OUT2 kPa Torr Psi
OUT1
OUT1 OUT2 kPa Torr PsiOUT1 OUT2 kPa Torr Psi
OUT1 OUT2 kPa Torr Psi
1. Press the S ET key under condition 1 bel ow while t.h1 is displayed to displ ay the present measurement value.
2. Check the measurement value and press the S et key to perform and complete teaching the first point.
3. Press the S et key under condi tion 2 below to display the present measurement val ue.
(This list of steps continues on the next page.)
