Omron FS-C4KU7DGES-F User Manual

No.20S046-00
34/62
FS-C4KU7DGES-F / FS-C4KU7DGES-M42 / FS-C2KU7DGES-F / FS-C2KU7DGES-M42 / FS-C2KU7DGES-C
Product Specifications and Use’s Guide
10.5 White balance
The color compensates with gain adjustment each color.
The gain for each color has to adjust each color has same brightness when taking flat white target.
The white balance control methods are listed in below:
Disable
OFF (Manual)
White balance control methods
GenICam Parameters
BalanceRatioSelector IEnumeration Type White balance control target color selection
Selection: “Red”, “Green” and “Blue”
BalanceRatio
[BalanceRatioSelector]
IFloat Type Color gain setting for color selects at “BalanceRatioSelector”
Range: 0 to 255
BalanceWhiteAuto IEnumeration Type White balance control method selection.
Selection: “Disable” and “Off”
Default: “Disable”
White balance control method selection
Disable
The white balance settings are disabled and sets as x1 gain for all color elements.
White balance “Disable” setting procedure
1. Sets “Disable” at “BalanceWhiteAuto”.
OFF
The white balance with “BalanceRatio” setting for Red, Green and Blue.
White balance “OFF” setting procedure
1. Sets “Off” at “BalanceWhiteAuto”.
2. Selects adjusting color from Red, Green or Blue at “BalanceRatioSelector”.
3. Sets gain for selected adjusting color at “BalanceRatio”.
10.6 Image Flip
The horizontal flip image can be selected by “ReverseX”.
The vertical flip image can be selected by “ReverseY”.
GenICam Parameters
ReverseX IBoolean Type Horizontal flip image ON / OFF selection
Selection: “False” (Horizontal flip is Off), “True” (Horizontal flip is On)
Default: “False” (Horizontal flip is Off)
ReverseX IBoolean Type Vertical flip image ON / OFF selection
Selection: “False” (Vertical flip is Off), “True” (Vertical flip is On)
Default: “False” (Vertical flip is Off)
