11.14 ChunkDataControl
Name Description
ChunkModeActive Activates the inclusion of Chunk data in the payload of the image.
ChunkSelector Selects which Chunk to enable or control.
ChunkEnable [ChunkSelector] Enables the inclusion of the selected Chunk data in the payload of the
image.
ChunkCounterSelector Selects which counter to retrieve data from.
ChunkCounterValue
[ChunkCounterSelector]
Returns the value of the selected Chunk counter.
ChunkGainSelector Selects which Gain to return.
ChunkGain [ChunkGainSelector] Returns the gain used to capture the image.
ChunkExposureTimeSelector Selects which Exposure Time to return.
ChunkExposureTime
[ChunExposureTimeSelector]
Returns the exposure time used to capture the image.
ChunkLineStatusAll Returns the status of all the I/O lines at the time of the Frame Start
internal event.
ChunkTimerSelector Selects which timer to retrieve data from.
ChunkTimerValue [ChunkTimerSelector] Returns the value of the selected Timer.
ChunkDeviceTemperature Indicates the value of the temperature when the image was acquired.
11.15 TestControl
Name Description
TestPendingAck Tests the device's pending acknowledge feature.
TestEventGenerate Generates a Test Event.
