No.20S046-00
51/62
FS-C4KU7DGES-F / FS-C4KU7DGES-M42 / FS-C2KU7DGES-F / FS-C2KU7DGES-M42 / FS-C2KU7DGES-C
Product Specifications and Use’s Guide
11.3 AcquisitionControl
Name Description
AcquisitionMode Sets the acquisition mode of the device.
AcquisitionStart Starts the Acquisition of the device.
AcquisitionStop Stops the Acquisition of the device at the end of the current Frame.
AcquisitionFrameCount Number of frames to acquire in Multi Frame Acquisition mode.
AcquisitionFrameRate Controls the acquisition rate (in Hertz) at which the frames are
captured.
AcquisitionLineRate Controls the rate (in Hertz) at which the Lines in Frame are captured.
FrameTimeoutEnable Enables the FrameTimeout.
FrameTimeout Sets the timeout for frame completion.
TriggerSelector Selects the type of trigger to configure.
TriggerMode [TriggerSelector] Controls if the selected trigger is active.
TriggerSoftware [TriggerSelector] Generates an internal trigger.
TriggerSource [TriggerSelector] Specifies the internal signal or physical input Line to use as the trigger
source.
TriggerActivation [TriggerSelector] Specifies the activation mode of the trigger.
TriggerDelay [TriggerSelector] Specifies the delay in microseconds (us) to apply after the trigger
reception before activating it.
ExposureMode Sets the operation mode of the Exposure.
ExposureTimeSelector Selects which exposure time is controlled by the Exposure Time
feature.
ExposureTime [ExposureTimeSelector] Sets the Exposure time when Exposure Mode is Timed and Exposure
Auto is Off.
11.4 AnalogControl
Name Description
GainSelector Selects which Gain is controlled by the various Gain features.
Gain [GainSelector] Controls the selected gain as an absolute physical value.
BalanceRatioSelector Selects which Balance ratio to control.
BalanceRatio [BalanceRatioSelector] Controls ratio of the selected color component to a reference color
component. It is used for white balancing.
BalanceWhiteAuto Controls the mode for automatic white balancing between the color
channels. The white balancing ratios are automatically adjusted.
