Item H3Y-2(-0)/H3Y-4(-0)
Rated supply voltage 24, 100 to 120, 200 to 230 VAC (50/60 Hz), 12, 24, 48, 125, 100 to 110 VDC (see note 1)
Operating voltage range All rated voltages except 12 VDC: 85% to 110% of rated supply voltage
12 VDC: 90% to 110% of rated supply voltage (see note 2)
Power consumption 24 VAC: Relay ON: 1.5 VA (1.1 W) (at 24 VAC, 60 Hz)
Relay OFF: 0.2 VA (0.1 W) (at 24 VAC, 60 Hz)
100 to 120 VAC: Relay ON: 1.5 VA (1.3 W) (at 120 VAC, 60 Hz)
Relay OFF: 0.8 VA (0.5 W) (at 120 VAC, 60 Hz)
200 to 230 VAC: Relay ON: 1.8 VA (1.5 W) (at 230 VAC, 60 Hz)
Relay OFF: 1.2 VA (0.9 W) (at 230 VAC, 60 Hz)
12 VDC: Relay ON: 0.9 W (at 12 VDC)
Relay OFF: 0.07 W (at 12 VDC)
24 VDC: Relay ON: 0.9 W (at 24 VDC)
Relay OFF: 0.07 W (at 24 VDC)
48 VDC: Relay ON: 1.0 W (at 48 VDC)
Relay OFF: 0.2 W (at 48 VDC)
100 to 110 VDC: Relay ON: 1.3 W (at 110 VDC)
Relay OFF: 0.3 W (at 110 VDC)
125 VDC: Relay ON: 1.3 W (at 125 VDC)
Relay OFF: 0.3 W (at 125 VDC)
Control outputs H3Y-2(-0): 5 A at 250 VAC, resistive load (cos
%
=1)
H3Y-4(-0): 3 A at 250 VAC, resistive load (cos
%
=1)
Note: 1. With DC ratings, single-phase full-wave rectified power sources may be used.
2. Usethe Timerwithin 90% to 110% of the ratedsupply voltage(95% to 110% for 12 VDC) when usingit continuously under an ambi-
ent operating temperature of 50
"
C.
3. The model designedfor a power consumption of 200 to 230 VAC at 50/60Hz can be used within the permissible voltagefluctuation
range of 170 to 230 VAC. Please contact your OMRON representative if models with specifications of 240VAC, 50/60 Hz (85% to
110%) are required.
