H3CR-A
H3CR-A
17
Mounting Track 50 cm (
l
)x7.3mm(t) PFP-50N
1m(
l
)x7.3mm(t) PFP-100N
1m(
l
)x16mm(t) PFP-100N2
End Plate PFP-M
Spacer PFP-S
Protective Cover Y92A-48B
Time Setting Ring
Setting a specific time
Y92S-27
Limiting the Setting Range Y92S-28
Panel Cover
Color (Munsell No.)
Model
Light Gray (5Y7/1) Y92P-48GL
Black (N1.5) Y92P-48GB
Medium Gray (5Y5/1) Y92P-48GM
Note: The Time Setting Ring and Panel Cover are sold together.
Hold-down Clip
Specification
Model
For PL08 and PL11 Sockets Y92H-7 (not for H3CR-A8EL)
Y92H-1 (for only H3CR-A8EL)
For PF085A Socket Y92H-8 (not for H3CR-A8EL)
Y92H-2 (for only H3CR-A8EL)
Specifications
General
Item H3CR-A/-AS H3CR-A8/-A8S H3CR-A8EL/-A8E
Operating mode A: ON-delay
B: Flicker OFF start
B2: Flicker ON start
C: Signal ON/OFF-delay
D: Signal OFF-delay
E: Interval
A: ON-delay
E: Interval
Pin type 11-pin 8-pin
Input type No-voltage input ---
Time-limit output type H3CR-A/-A8: Relay output (DPDT)
H3CR-AS/-A8S: Transistor output (NPN/PNP)*
Relay output (SPDT)
Instantaneous output type --- Relay output (SPDT)
Mounting method DIN track mounting, surface mounting, and flush mounting
EMC Emission Enclosure: EN55011 Group 1 class A
Emission AC Mains: EN55011 Group 1 class A
Immunity ESD: IEC801-2: 4 kV contact discharge (level 2)
8 kV air discharge (level 3)
Immunity RF-interference: ENV50140: 10 V/m (80 MHz to 1 GHz) (level 3)
Immunity Conducted Disturbance: ENV50141: 10 V (0.15 to 80 MHz) (level 3)
Immunity Burst: IEC801-4: 2 kV power-line (level 3)
2 kV I/O signal-line (level 4)
Approved standards UL508, CSA C22.2 No.14, LR/NK
Conforms to VDE0435/2021, VDE0110
Conforms to EN50081-2, prEN50082-2
*The internal circuits are optically isolated from the output. This enables application of either NPN or PNP transistors.
Time Ranges
Time unit s (sec) min h(hrs) x10 h (10 h)
Setting 0 Instantaneous output (To obtain instantaneous output, set to below 0.) (see note)
1.2 0.05 to 1.2 0.12 to 1.2 1.2to12
3 0.3to3 3to30
12 1.2to12 12 to 120
30 3to30 30 to 300
Note: Instantaneous output is available with all H3CR-A models.
