Omron Micro A-I-R NE-U22 User Manual

How to Prepare the Power Source
8
Correct Use of the Unit How to Prepare the Power Source
How to use the optional AC Adapter
Please note that this AC Adapter is not a battery charger.
1 Place the Main Unit on the AC Adapter
Connection Stand as shown in the Figure.
How to remove the AC Adapter from the Main Unit
(1) Unplug the power plug from the
electric outlet.
(2) Unlock the Main Unit by pushing in
both ends of the Main Unit Locking
Board of the AC Adapter Connection
Stand with your fingers.
2 Plug in the power plug of AC Adapter to the electric outlet.
(1) Unplug
(2) Push both ends to
remove the Main Unit.
Main Unit Locking Board
Main Unit Locking Board
- Push in the AC Adapter until it clicks
and is locked to the Stand.
Connection is completed.
Connect the unit to the power source before starting to use it.
Use batteries or optional AC Adapter as the power source.
EN-p2-20-(NE-U22)-3 3/25/02 4:48 PM Page 8

Omron Micro A-I-R NE-U22 Specifications

Power

power source	3 VDC (two AA alkaline batteries), 2.4 VDC (two AA nickel-hydrogen batteries)
power consumption	1.5 W

Technical Specifications

ultrasonic frequency	180 kHz
nebulization rate	0.25 ml / minute or more
particle size	5 µm

Capacity and Dimensions

medication bottle capacity	7 ml
external dimensions	38 (W) x 104 (H) x 51 (D) mm
weight	97 g

Battery and Operating Life

battery life with continuous nebulization	4 hours
battery life with daily use	8 days
operating temperature	10 to 40°C
