Omron MX2 Product Information

2 Frequency inverters
Type designation
200 V class
400 V class
Specifications
Single-phase: MX2@ AB001 AB002 AB004 AB007
1
1. Three phase model use forced-air-cooling but single phase model is self cooling.
AB015 AB022 - - - - -
Three-phase: MX2@ A2001 A2002 A2004 A2007 A2015 A2022 A2037 A2055 A2075 A2110 A2150
Motor
kW
2
2. Based on a standard 3-Phase standard motor.
For VT setting 0.2 0.4 0.55 1.1 2.2 3.0 5.5 7.5 11 15 18.5
For CT setting 0.1 0.2 0.4 0.75 1.5 2.2 3.7 5.5 7.5 11 15
Output
characteristics
Inverter capacity kVA
200 VT
0.4 0.6 1.2 2.0 3.3 4.1 6.7 10.3 13.8 19.3 23.9
200 CT
0.2 0.5 1.0 1.7 2.7 3.8 6.0 8.6 11.4 16.2 20.7
240 VT
0.4 0.7 1.4 2.4 3.9 4.9 8.1 12.4 16.6 23.2 28.6
240 CT
0.3 0.6 1.2 2.0 3.3 4.5 7.2 10.3 13.7 19.5 24.9
Rated output current (A) at VT 1.2 1.9 3.5 6.0 9.6 12.0 19.6 30.0 40.0 56.0 69.0
Rated output current (A) at CT 1.0 1.6 3.0 5.0 8.0 11.0 17.5 25.0 33.0 47.0 60.0
Max. output voltage Proportional to input voltage: 0..240 V
Max. output frequency 1000 Hz
3
3. Above 400 Hz with some function limitation.
Power
supply
Rated input voltage
and frequency
Single-phase 200..240 V 50/60 Hz
3-phase 200..240 V 50/60 Hz
Allowable voltage fluctuation -15%..+10%
Allowable frequency fluctuation 5%
Braking torque
At short-time
deceleration
At capacitor
feedback
100%: <50Hz
50%: <60Hz
70%:
<50Hz
50%:
<60Hz
Approx 20% -
Cooling method
Self cooling
Forced-air-cooling
Three-phase: MX2@ A4004 A4007 A4015 A4022 A4030 A4040 A4055 A4075 A4110 A4150
Motor
kW
1
1. Based on a standard 3-Phase standard motor.
For VT setting 0.75 1.5 2.2 3.0 4.0 5.5 7.5 11 15 18.5
For CT setting 0.4 0.75 1.5 2.2 3.0 4.0 5.5 7.5 11 15
Output
characteristics
Inverter capacity kVA
380 VT
1.3 2.6 3.5 4.5 5.7 7.3 11.5 15.1 20.4 25.0
380 CT
1.1 2.2 3.1 3.6 4.7 6.0 9.7 11.8 15.7 20.4
480 VT
1.7 3.4 4.4 5.7 7.3 9.2 14.5 19.1 25.7 31.5
480 CT
1.4 2.8 3.9 4.5 5.9 7.6 12.3 14.9 19.9 25.7
Rated output current (A) at VT 2.1 4.1 5.4 6.9 8.8 11.1 17.5 23.0 31.0 38.0
Rated output current (A) at CT 1.8 3.4 4.8 5.5 7.2 9.2 14.8 18.0 24.0 31.0
Max. output voltage Proportional to input voltage: 0..480 V
Max. output frequency 1000 Hz
2
2. Above 400 Hz with some function limitation.
Power
supply
Rated input voltage
and frequency
3-phase 380..480 V 50/60 Hz
Allowable voltage
fluctuation
-15%..+10%
Allowable frequency
fluctuation
5%
Braking torque
At short-time
deceleration
*3
At capacitor
feedback
100%: <50Hz
50%: <60Hz
70%:
<50Hz
50%:
<60Hz
-
Cooling method
Self cooling Forced-air-cooling
MX2 series
A: Standard specs
MX2AB002-E
Voltage:
B: Single-phase 200 VAC
2: Three-phase 200 VAC
4: Three-phase 400 VAC
Max. applicable motor output
002: 0,2 kW
~
150: 15,0 kW
E: Europe standard
