Omron MX2 Product Information

6 Frequency inverters
Chokes
Resistor dimensions
400 V
AX-RAO16300038-DE 120 70 120 80 52 5.5 1.78
AX-RAO11800053-DE 120 80 120 80 52 5.5 2.35
AX-RAO07300080-DE 120 80 120 80 62 5.5 2.35
AX-RAO04600110-DE 180 85 190 140 55 6 5.5
AX-RAO03600160-DE 180 85 205 140 55 6 6.5
AX-RAO02500220-DE 180 95 205 140 55 6 9.1
AX-RAO02000320-DE 180 105 205 140 85 6 11.7
Reference D
diameter
Motor
kW
Dimensions Weight
kg
L W H X Y m
AX-FER2102-RE 21 < 2.2 85 22 46 70 - 5 0.1
AX-FER2515-RE 25 < 15 105 25 62 90 - 5 0.2
AX-FER5045-RE 50 < 45 150 50 110 125 30 5 0.7
Voltage Reference
Dimensions Weight
kg
A
B2 C2 D E F
X
H
YW
Ø m
L
Ø d
Type Fig.
Dimensions
Weight
L H M I T kg
AX-REM00K1400-IE
1
105 27 36 94 - 0.2
AX-REM00K2070-IE
AX-REM00K2120-IE
AX-REM00K2200-IE
AX-REM00K4075-IE
200 27 36 189 - 0.425AX-REM00K4035-IE
AX-REM00K4030-IE
AX-REM00K5120-IE 260 27 36 249 - 0.58
AX-REM00K6100-IE
320 27 36 309 - 0.73
AX-REM00K6035-IE
AX-REM00K9070-IE
2 200 62 100 74 - 1.41AX-REM00K9020-IE
AX-REM00K9017-IE
AX-REM01K9070-IE
3 365 73 105 350 70 4
AX-REM01K9017-IE
AX-REM02K1070-IE
4
310 100 240 295 210 7
AX-REM02K1017-IE
AX-REM03K5035-IE
365 100 240 350 210 8
AX-REM03K5010-IE
AX-REM00K1200
Fig 1
Fig 3
Fig 4
Fig 2
