8 Connecting to Panasonic Industrial Devices SUNX PLCs
NB-series Programmable Terminals Host Connection Manual (V108)
8-2 Communication Parameters and Cable Fabrication
8
8-2 Communication Parameters and
Cable Fabrication
Note 1 Only FP0 (C10CRM/C10CRS/C14CRM/C14CRS/C16T/C16CP/C32CT/C32CP) has RS232C communi-
cation port.
2 Only FP1 (C24/C40/C56/C72) has RS232C communication port.
3 Only FP1 (C20R/C20T/C32T) has RS232C communication port.
4 AFP245 is the multi-communication unit for FP2/FP2SH. AFP2803, AFP2804 and AFP2805 are the com-
munication modules connecting to AFP2465.
Series CPU Link Module COMM Type Parameter Cable
FP FP Tool port on the Control unit RS232C Refer to
Section 8-3
Self-made cable
required
AFPG801
AFPG802
AFPG806
AFPG803 RS485
AFPG806
FP0 Tool port on the Control unit RS232C
RS232C port on the Control unit
FP1
FP-M
Tool port on the Control unit RS232C
RS232C port on the Control unit
FP2
FP2SH
Tool port on the Control unit RS232C
RS232C port on the Control unit
AFP2462
AFP2465 AFP2803
AFP2804 RS422
AFP2805 RS485
FP3 Tool port on the Control unit RS232C
AFP3462
AFP3463 RS422
FP-e Tool port on the Control unit RS232C
AFPE224300 RS232C
AFPE214325
AFPE224305
AFPE224302 RS485
AFPE214322
FP10SH
FP10S
Tool port on the Control unit RS232C
RS232C port on the Control unit
AFP3462
FP-X RS232C port on the Control unit RS232C
