Appendix 1 Specifications
Appendix 1 Specifications
A-1-1 General Specifications
Specifications
Item
NS12-TS0@-V1
NS12-TS0@-V2
NS10-TV0@-V1
NS10-TV0@-V2
NS8-TV@@-V1
NS8-TV0@-V2
NS5-SQ0@-V1
NS5-SQ0@-V2
NS5-TQ0@-V2
NS5-MQ0@-V2
Rated power supply volt-
age
24 VDC
Allowable voltage range 20.4 to 27.6 VDC (24 VDC ±15%)
Allowable input power
interruption time
No restriction.
Power consumption 25 W max 15 W max.
Ambient operating
temperature
0 to 50°C (See notes 1, 2, and 3.)
Storage temperature −20 to 60°C (See note 2.)
Ambient operating
humidity
35% to 85% (0 to 40°C) with no condensation
35% to 60% (40 to 50°C) with no condensation
Operating environment No corrosive gases.
Noise immunity Conforms to IEC61000-4-4, 2 KV (power lines)
Vibration resistance
(during operation)
10 to 57 Hz with 0.075 mm amplitude and 57 to 150 Hz with 9.8 m/s
2
acceleration for
30 min in each of X, Y, and Z directions
Shock resistance
(during operation)
147 m/s
2
3 times in each of X, Y, and Z directions.
Dimensions 315 × 241 × 48.5 mm (W × H × D) 232 × 177 × 48.5 mm
(W × H × D)
195 × 142 × 54 mm
(W × H × D) Width
Panel cutout dimensions Width 302 ×
Height 228
mm
Panel thickness:
1.6 to 4.8 mm
+1
0
+1
0
Width 302
×
Height 228
mm
Panel thickness:
1.6 to 4.8 mm
+1
0
+1
0
Width 220.5
+0
×
Height 165.5
+0
mm
Panel thickness:
1.6 to 4.8 mm
.5
0
.5
0
184
+0
× Height
131
+0
mm
Panel thickness:
1.6 to 4.8 mm
.5
0
.5
0
Weight 2.5 kg max. 2.0 kg max. 1.0 kg max.
Enclosure rating Front panel: Equivalent to IP65F (NEMA4) (See note 4.)
Battery life 5 years (at 25°C)
The SRAM and RTC will be backed up for 5 days after the battery runs low (indicator lights
orange).
The SRAM and RTC will be backed up by a super capacitor for 5 minutes after removing
the old battery (i.e., after turning ON power after 5 minutes).
International standards UL 1604 Class 1 Division 2, EC Directives
Note 1. The operating temperature is subject to the following restrictions, depending on the
mounting angle and whether an Expansion Unit is installed or not.
• Without any Expansion Unit Installed
- NS12-V1/-V2, NS10-V1/-V2, NS8-V1/-V2
Mounting angle of 0° to less than 30° to the horizontal:
Operating temperature range of 0 to 45°C
Mounting angle of 30° to 90° or less to the horizontal:
Operating temperature range of 0 to 50°C
- NS5-V1/-V2
Mounting angle of 0° to 90° or less to the horizontal:
Operating temperature range of 0 to 50°C
A-3
