4 - 7
4 Installation and Wiring
NX-series Position Interface Units User’s Manual (W524)
4-1 Installing Units
4
4-1-4 Installation Orientation
The Slave Terminal can be installed in any of the following six orientations.
(A) is the upright installation orientation and (B) to (F) are installation orientations other than upright.
However, there are restrictions on the installation orientation and restrictions to the specifications that
can result from the Communications Coupler Units and NX Units that are used.
For detailed restrictions, refer to the user’s manuals for the Communications Coupler Unit, NX Units,
and NX-series System Units that you will use.
4-1-4 Installation Orientation
(A)
(B)
(E) Up
Down
(C)
(F)
(D)
