Omron NX-SL5500 User Manual

A-1
Dimensions
Dimensions of the Units are shown as follows. The unit of dimension is millimeter.
A-1-1
Safety CPU Unit
NX-SL5500/NX-SL5700
100
(2.1)
1.1 71
5.8
(72.1)
30
32.1
4.5
1.51.5
Unit: mm
NX-SL3300/NX-SL3500
100
30
71
Appendices
A - 3
NX-series Safety Control Unit User's Manual (Z930)
A-1 Dimensions
A
A-1-1 Safety CPU Unit

Omron NX-SL5500 Specifications

General

Brand	Omron
Model	NX-SL5500
Category	Controller
Language	English
