Omron SYSMAC CV1000 Installation Guide

21
Mounting Locations The following table below summarizes the Units that can be mounted to CPU,
Expansion CPU, Expansion I/O, and Slave Racks. For detailed information
about the Units listed below , refer to the operation manual for the individual Unit.
Unit CPU
Rack
Expansion
CPU Rack
Expansion
I/O Racks
Slave Racks (CV- or
C-series)
Remarks
16-/32-/64-point
I/O Units
Yes Yes Yes Yes ---
Service Power
Supplies
Yes Yes Yes Yes ---
Interrupt Input
Units
Yes Yes No No Up to 4 Units can be mounted.
When mounting to the Expansion
CPU Rack, set the rack number
to 1.
C500 Special I/O
Units
Yes Yes Yes Yes
The following cannot be
mounted to SYSMAC
BUS/2 Slave Racks:
NC103, NC221, NC222,
CP131, FZ001, PID01,
and MCC01.
The following cannot be
mounted to SYSMAC
BUS Slave Racks:
NC221, NC222, CT041,
and FZ001.
All other Special I/O Units
can be mounted.
Up to 8 of the following Units can
be mounted: Analog Input, Analog
Output, High-speed Counter, PID,
Position Control, Magnetic Card,
ASCII, ID Sensor
, and Ladder
Program I/O. Position Control
Units, NC103-E, and PID Units
use 2 slots.
READ(190)/WRIT(191) cannot be
used with Units mounted to
SYSMAC BUS Slave Racks.
BASIC Units Yes Yes No No
Up to 16 CPU Bus Units can be
d i h h PC i l di 2
Temperature
Controller Data
Link Unit
Yes Yes No No
used with each PC, including 2
Remote I/O Master Units for the
CV500 or CVM1-CPU01-EV2 or 4
for the CV1000 CV2000
Personal
Computer Units
Yes Yes No No
f
or t
h
e
CV1000
,
CV2000
,
CVM1-CPU11-EV2, or
CVM1-CPU21-EV2, up to a 4
SYSMAC NET
Link Units
Yes Yes No No
CVM1-CPU21-EV2
,
u
to
a
4
each of the SYSMAC NET Link,
SYSMAC LINK Units, Host Link
U it Eth t U it d 1
SYSMAC LINK
Units
Yes Yes No No
,
Unit, or Ethernet Unit, and 1
CompoBus/D Master Unit.
AP lC t U it
SYSMAC BUS/2
Remote I/O
Master Units
Yes Yes No No
A Personal Computer Unit
requires 4 slots.
Ethernet Units Yes Yes No No
CompoBus/D
Master Unit
Yes Yes No No
SYSMAC BUS
Remote I/O
Master Units
Yes Yes Yes No Up to 4 Units can be mounted to
a CV500 or CVM1-CPU01-EV2
and eight Units to a CV1000,
CV2000, CVM1-CPU11-EV2, or
CVM1-CPU21-EV2.
SYSMAC BUS
I/O Link Units
Yes Yes Yes No I/O cannot be set to 16 input/16
output.
