A-5VL
SERVICE MANUAL
INTEGRATED AMPLIFIER
Black and Silver models
MODEL A-5VL (B)/(S)
120V AC, 60Hz
220-240V AC, 50/60Hz
BMDC
BMMB, SMMB
SMDF
SMMR
Ref. No. 4148
062009
RC-751S
MENU
SHUFFLE REPEAT
SELECT
MODE DISPLAY
PLAYLIST
ALBUM
BAND MODE PRESET
SAFETY-RELATED COMPONENT
WARNING!!
COMPONENTS IDENTIFIED BY MARK ON THE
SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE
CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.
REPLACE THESE COMPONENTS WITH ONKYO
PARTS WHOSE PART NUMBERS APPEAR AS SHOWN
IN THIS MANUAL.
MAKE LEAKAGE-CURRENT OR RESISTANCE
MEASUREMENTS TO DETERMINE THAT EXPOSED
PARTS ARE ACCEPTABLY INSULATED FROM THE
SUPPLY CIRCUIT BEFORE RETURNING THE
APPLIANCE TO THE CUSTOMER.
